PIONEER TS-WX206A/XCN1/EW7 Service Manual

Cover page of PIONEER TS-WX206A/XCN1/EW7 Service Manual

Service Manual for PIONEER TS-WX206A/XCN1/EW7, downloadable as a PDF file.

We also have owner's manual to this model.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 8 pages
  • File size: 0.54 MB
  • Available language versions: English
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • the manual includes circuit diagrams,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6Thumbnail of page 7Thumbnail of page 8
Thumbnail of page 9
background image
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2008
c
ORDER NO.
TS-WX206A
TRT1162
H-IZX JULY 2008 Printed in Japan
AMPLIFIED BANDPASS SUBWOOFER
XCN1/EW7
1. SPECIFICATIONS
· Speaker specifications
Size .................................................................
200mm (8"Dia.)
High compliance, rolled edge
Heat-resistant voice coil
Strontium magnet : 650g (23oz)
· Amplifier
Max. Power output ................................................. 150W (80Hz)
DIN output power (DIN45324, 65Hz, 2
+B=14.4V) ......... 70W
INPUT LEVEL (at Gain Max)
(RCA) .................................................. 100mV+100mV / 20k
(Speaker line) ........................................................ 2V+2V / 5k
Power source ......................... DC14.4V (10.8~15.6V allowable)
Max. current consumption ..................................................... 10A
Grounding .......................................................... Negative ground
· Speaker system ...................................................... Bandpass type
· Cabinet meterial ..................................................... Particle board
· Sesitivity ....................................... 107dB / W (In car, SUV type)
· Size .......... 412mm (16-1/4")(W)
×274mm (10-3/4")(D)×316mm (12-1/2")(H)
· Weight (including accessory parts) ................. 9.67kg (21lb 5oz)
· Gross weight (including packaging) ............. 11.3kg (24lb 14oz)
Note :
Specifications and the design are subject to possible
modification without notice due to improvements.
¶ Figure of Measurement
2. HOW TO INSTALL
background image
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2008
c
ORDER NO.
TS-WX206A
TRT1162
H-IZX JULY 2008 Printed in Japan
AMPLIFIED BANDPASS SUBWOOFER
XCN1/EW7
1. SPECIFICATIONS
· Speaker specifications
Size .................................................................
200mm (8"Dia.)
High compliance, rolled edge
Heat-resistant voice coil
Strontium magnet : 650g (23oz)
· Amplifier
Max. Power output ................................................. 150W (80Hz)
DIN output power (DIN45324, 65Hz, 2
+B=14.4V) ......... 70W
INPUT LEVEL (at Gain Max)
(RCA) .................................................. 100mV+100mV / 20k
(Speaker line) ........................................................ 2V+2V / 5k
Power source ......................... DC14.4V (10.8~15.6V allowable)
Max. current consumption ..................................................... 10A
Grounding .......................................................... Negative ground
· Speaker system ...................................................... Bandpass type
· Cabinet meterial ..................................................... Particle board
· Sesitivity ....................................... 107dB / W (In car, SUV type)
· Size .......... 412mm (16-1/4")(W)
×274mm (10-3/4")(D)×316mm (12-1/2")(H)
· Weight (including accessory parts) ................. 9.67kg (21lb 5oz)
· Gross weight (including packaging) ............. 11.3kg (24lb 14oz)
Note :
Specifications and the design are subject to possible
modification without notice due to improvements.
¶ Figure of Measurement
2. HOW TO INSTALL
background image
2
TS-WX206A
12
3
4
C
D
F
A
B
E
1
23
4
D
C
A
B
A
B
C
D
3. EXPLODED VIEWS AND PARTS LIST
3.1 EXTERIOR SECTION
NOTES : Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The > mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to
mark on the product are used for disassembly.
For the applying amount of lubricants or glue, follow the instructions in this manual.
(In the case of no amount instructions, apply as you think it appropriate.)
background image
3
TS-WX206A
5
67
8
5
6
7
8
C
D
F
A
B
E
· EXTERIOR SECTION PARTS LIST
1Woofer
20-230AZ/XCN
×1
2 PCB Unit
TWX1048
×1
NSP
3
CONTROL Unit
TWG1020
×1
NSP
4
AMP Unit
TWH1028
×1
5 Port Grille Assy
TXK1659
×1
NSP
6
Port Net
TFX1052
×2
NSP
7
Port Pipe
TFX1053
×2
NSP
8
Port Grille
TLK1812
×1
9
Packing
TEB1488
×1
10 Terminal Panel
TLK1816
×1
11 Cabinet
TMM1080
×1
12 Heat Sink
TNA1736
×1
NSP
13 Lock Tie
CNV-754
×2
14 Cord
TDC2676
×1
NSP
15 Cushion
TED1918
×2
16 Cord
TDC2677
×1
17 Connection Cord
TDE1137
×1
NSP
18 Bushing
TEB1485
×1
NSP
19 Cushion
TED1945
×1
NSP
20 Cushion
TED1946
×1
NSP
21 Cushion
TED1947
×1
22 Packing
TEB1476
×1
23 Sound Absorbent
TED1951
×2
24 Screw
TBA1227
×6
25 Screw
BBZ30P100FTB
×13
26 Screw
BNC40P160FNI
×6
NSP
27 Screw
BPZ30P080FTB
×1
28 Screw
BPZ30P100FNI
×8
29 Screw
ONC40P140FTB
×10
30 Screw
PMA30P080FTB
×4
1 Mounting Kit
TEA2104
×1
1-1 Screw
BNC40P250FTB
×8
NSP
1-2 Mounting Metal
TNA1914
×4
2 Belt Assy
TXH1420
×1
3 Cord
TDC2606
×1
4 Cord
TDC2726
×1
5 Cord
TDC2245
×1
Operating Instructions
TRD1233
×1
Operating Instructions
TRD1335
×1
Mark No. Description
Part No.
Remarks
Mark No. Description
Part No.
Remarks
3.2 ACCESSORY PARTS LIST
Mark No. Description
Part No.
Remarks
Accessories
3
4
5
2
1
1-1
1-2
BNC40P250FTB
TNA1914
TXH1420
TDC2606
TDC2726
TDC2245
Screw
Mounting Metal
Belt
Cord
Cord
Cord
Protector
TEC2075
1 pair
Packing Case
THF4926
×1
3.3 PACKING PARTS LIST
Mark No. Description
Part No.
Remarks
background image
4
TS-WX206A
12
3
4
C
D
F
A
B
E
1
23
4
A B
RCA INPUT
SP INPUT
SP INPUT
SP INPUT
REMOTE
GND
BACKUP
R
L
3
4
1
2
4
5
6
1
REMOTE
GND
L+IN
L­IN
R+IN
R­IN
L+IN
L­IN
0.5A
1
2
3
4
1
2
3
4
1
2
4
5
3
6
10A
R+IN
R­IN
14.4V
BACKUP
2
3
CONTROL UNIT (TWG1020)
A
CN105
TKS1107
CN104
TKS1063
CN103
TKS1062
TDC2268
TDC2245
TDC2244
TDC2606
CN101
TKS1123
CN201
TKS1123
D101
GP30DL-6372
R151
2.2k
R103
10k
R107
10k
R111
10k
R112
100
R108
10k
R110
10k
R109
10k
R119
75k
R118
39k
R117
68k
R115
3.3k
R116
27k
R121
12k
R123
12k
R122
12k
R124
510
R120
12k
NOR
REV
SW101
TSG1010
R113
510
R114
10k
VR101
TCS1018
5k-B
VR102
TCS1019
20k-B
VR102
TCS1019
20k-B
R102
10k
R104
10k
R101
10k
R105
10k
R106
10k
C103
2.2/50
C101
2.2/50
C105
100p
C107
100p
C111
100p
C110
0.22
C112
0.15
C114
0.15
C113
0.068
R138
10k
4.2V
GND
14.4V
C134
100/16
C115
0.068
C109
100p
C108
100p
C132
820p
Q131
2SC2458
C106
100p
C102
2.2/50
C104
2.2/50
C131
0.1
R153
2.2k
R152
2.2k
R154
2.2k
R156
240
R155
240
ISOLATOR
MIXER
LPF AMP
BUFFER
PHASE
FREQ
LPF AMP
(NP)
(NP)
(NP)
(NP)
D131
ERA15-02
L132
(EMI)
D132
RD6R8JS
D133
1SS133
R133
4.7k
R134
22k
GND
1
GND
2
BACKUP
3
BACKUP
GND
GND
BACKUP
BACKUP
4
1
2
3
4
IC101
UPC4570HA
IC102
UPC4570HA
IC102
UPC4570HA
IC101
UPC4570HA
IC103
UPC4570HA
IC103
UPC4570HA
1/2
1/2
1/2
2/2
1/2
2/2
2/2
2/2
7
7
7
66
6
8
8
8
4
4
4
3
3
3
5
5
5
2
2
2
9
9
9
4. PCB UNIT
4.1 SCHEMATIC DIAGRAM
background image
5
TS-WX206A
5
67
8
5
6
7
8
C
D
F
A
B
E
A B
SPEAKER
AMP UNIT (TWH1028)
B
R137
10k
D134
SLH-34VC3F
R136
10k
R135
1k
R201
47k
C206
0.022
C205
0.22
C202
0.22
C208
10/50
C207
1
C211
100/16
C221
100/10
C201
0.1
C223
220/10
C222
100/16
C224
100/10
R202
3.3k
R203
8.2k
R204
100
R205
1.6k
TH201
TCX1005
Q201
DTA114ES
Q203
DTC114ES
Q202
2SC2458
Q222
2SC5029
Q221
2SA1892
8.5V
13.7V
14.3V
Q224
2SC2458
Q223
2SC2458
D226
RD6R8JS
D223
RD9R1JS
NR201
TCX1014
L201
(EMI)
L221
(EMI)
D224
1SS133
D225
1SS133
D221
1SS133
D222
1SS133
R225
100
R224
5.6k
R223
1k
R222
10k
R221
10k
R229
330
R227
10k
R228
10k
C225
33/50
R226
47k
D202
1SS133
C210
0.1
C203
0.22
C204
0.22
14.3V
C209
4700/16
IC201
PAL007C
Q132
2SC2458
C133
100/16
THERMAL
POWER AMP
SWITCHING
REGULATOR
SWITCHING
STBY
MUTE
CN102
TKS1125
CN203
TKS1075
CN202
TKS1125
SIG
1
SIG G
2
8.5V
3
REMOTE
POWER IND
4
5
1
2
3
4
5
14
20
6
25
21
8
23
2
17
19
5
3
18
9
24
7
1
4
16
10
1
2
3
4
1
2
3
4
15
13
12
11
22
4.0V
IN1
OUT1+
OUT1­
OUT2+
OUT2­
IN2
: Audio Signal Route
÷ When ordering service parts, be sure to refer to "EXPLODED VIEWS and PARTS LIST"
or "PCB PARTS LIST".
