background image
ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2000
c
X-LA21
RRV2370
T ­ ZZK OCT. 2000 Printed in Japan
COMPACT MINI COMPONENT
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Component
Model
Service manual
Remarks
COMPACT MINI COMPONENT
X-LA21
RRV2370
This manual.
STEREO CD TUNER
XC-LA21
RRV2392
STEREO POWER AMPLIFIER
M-LA21
RRV2393
SPEAKER SYSTEM
S-LA21
RRV2394
¶ X-LA21 is combination of the following components.
¶ Table of product which is necessary when repairing.
: Unnecessary.
: Necessity.
Repaired product
Needed product
Remarks
XC-LA21
M-LA21
STEREO CD TUNER
XC-LA21
­­
STEREO POWER AMPLIFIER
M-LA21
­­
* STEREO CD TUNER operates single and normally. It is not necessary to supply external DC power supply.
Type
Model
Power Requirement
The voltage can be converted by
X-LA21
the following method.
DBDXCN
AC110-127V/220-230/240V
With the voltage selector
DDXCN/AR
AC110-127V/220-230/240V
With the voltage selector
background image
ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2000
c
X-LA21
RRV2370
T ­ ZZK OCT. 2000 Printed in Japan
COMPACT MINI COMPONENT
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Component
Model
Service manual
Remarks
COMPACT MINI COMPONENT
X-LA21
RRV2370
This manual.
STEREO CD TUNER
XC-LA21
RRV2392
STEREO POWER AMPLIFIER
M-LA21
RRV2393
SPEAKER SYSTEM
S-LA21
RRV2394
¶ X-LA21 is combination of the following components.
¶ Table of product which is necessary when repairing.
: Unnecessary.
: Necessity.
Repaired product
Needed product
Remarks
XC-LA21
M-LA21
STEREO CD TUNER
XC-LA21
­­
STEREO POWER AMPLIFIER
M-LA21
­­
* STEREO CD TUNER operates single and normally. It is not necessary to supply external DC power supply.
Type
Model
Power Requirement
The voltage can be converted by
X-LA21
the following method.
DBDXCN
AC110-127V/220-230/240V
With the voltage selector
DDXCN/AR
AC110-127V/220-230/240V
With the voltage selector
background image
2
X-LA21
SYSTEM
SPEAKER
REAR
XC-LA21
REAR
M-LA21
FRONT
FRONT
FRONT
FRONT
TOP SIDE
TOP SIDE
13
3
1
5
14
7
4
11
17
15
16
19
20
DDXCN/AR Only
9(2/2)
10
10
9(1/2)
8(2/2)
12
8(1/2)
18
18
11
8(2/2)
12
12
8(1/2)
6
2
1. EXPLODED VIEWS AND PARTS LIST
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The
mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to
mark on product are used for disassembly.
NOTES:
1.1 PACKING
(1) PACKING PARTS LIST
Mark No.
Description
Part No.
1
AM Loop Antenna
ANT-PMT1E-AL
2
Remote Control Unit
AXD7289
3
RCA Audio Cable
122003220100
NSP
4
`AAA' Size R03 Batteries
130115004000
5
FM Wire Antenna
132030001001
6
Power-cord Plug Conversion Adaptor
138011722000
7
Battery Door
500RC4603070
8
Polyform Unit
800PMT190001
9
Polyfoam (Speaker)
800PMT390000
10
Poly Foam Sheet (C) SP
801999000002
11
Polythenefoam Sheet
801999000005
NSP
12
PE Polybag (AC Cord)
805032115000
NSP
13
PE Polybag (Remocon)
805035105000
NSP
14
PE Polybag (Antenna)
805070100000
NSP
15
PE Polybag (I Book)
805085140000
16
Operating Instructions
811PMT391011
(English/Spanish/Chinese)
17
Carton
See Contrast table (2)
18
Corrugate Card
815001405213
19
Additional Sheet
810PMT395010
20
Correction Sheet
See Contrast table (2)
(2) CONTRAST TABLE
X-LA21/DBDXCN and DDXCN/AR are constructed the same except for the following :
Part No.
Mark No.
Symbol and Description
X-LA21
X-LA21
Remarks
/DBDXCN
/DDXCN/AR
17
Carton
813PMT393020
813PMT393010
20
Correction Sheet
Not used
810PMT395020
