ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2002
MD
DVD/CD
VOLUME
DIRECT PLAY OPERATION
STEREO DVD/CD MD RECEIVER SYSTEM
VIDEO
DVD/CD
66
STANDBY/ON
TIMER
MD
MINIDISC LOADING MECHANISM
LINE
FM/AM
UP
DOWN
PULL OPEN
HIGH QUALITY SOUND COMPACT MINI COMPONENT
X-SV5DV
MP3
1
XV-SV5DV
RRV2673
DVD/CD MD RECEIVER
XV-SV5DV
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model
Type
Power Requirement
Reginal restriction
codes (Region No.)
Remarks
XV-SV5DV
NXCN/HK
AC220V
3
For details, refer to "Important symbols for good services" on the next page.
T-ZZK SEPT. 2002 printed in Japan
background image
ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2002
MD
DVD/CD
VOLUME
DIRECT PLAY OPERATION
STEREO DVD/CD MD RECEIVER SYSTEM
VIDEO
DVD/CD
66
STANDBY/ON
TIMER
MD
MINIDISC LOADING MECHANISM
LINE
FM/AM
UP
DOWN
PULL OPEN
HIGH QUALITY SOUND COMPACT MINI COMPONENT
X-SV5DV
MP3
1
XV-SV5DV
RRV2673
DVD/CD MD RECEIVER
XV-SV5DV
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model
Type
Power Requirement
Reginal restriction
codes (Region No.)
Remarks
XV-SV5DV
NXCN/HK
AC220V
3
For details, refer to "Important symbols for good services" on the next page.
T-ZZK SEPT. 2002 printed in Japan
background image
XV-SV5DV
2
1234
123
4
C
D
F
A
B
E
SAFETY INFORMATION
This service manual is intended for qualified service technicians ; it is not meant for the casual
do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
trainedto properly and safely repair complex products such as those covered by this
manual.Improperly performed repairs can adversely affect the safety and reliability of the product
and mayvoid the warranty. If you are not qualified to perform the repair of this product properly and
safely, youshould not risk trying to do so and refer the repair to a qualified service technician.
WARNING !
THE AEL (ACCESSIBLE EMISSION LEVEL) OF THE LASER POWER OUTPUT IS LESS THAN CLASS 1
BUT THE LASER COMPONENT IS CAPABLE OF EMITTING RADIATION EXCEEDING THE LIMIT FOR
CLASS 1.
A SPECIALLY INSTRUCTED PERSON SHOULD DO SERVICING OPERATION OF THE APPARATUS.
LASER DIODE CHARACTERISTICS
FOR DVD : MAXIMUM OUTPUT POWER : 5 mW
WAVELENGTH : 650 nm
FOR CD :
MAXIMUM OUTPUT POWER : 5 mW
WAVELENGTH : 780 nm
LASER DIODE CHARACTERISTICS
FOR MD : MAXIMUM OUTPUT POWER : 40mW
WAVELENGTH: 775 - 800 nm
Additional Laser Caution
for DVD
: See page 97.
1. Laser Interlock Mechanism
· Loading switch (S101 on the LOAB Assy) is used for interlock
mechanism of the laser.
When this switch turned ON in SW2 (XCLOSE) side (OPEN signal is
0V and XCLOSE signal is 3.5V), a laser becomes the status which
can completely oscillate.
Furthermore, the laser completely oscillates in the disc judgment and
disc playback.
When player is power ON state and laser diode is not completely
oscillating, 780nm laser diode is always oscillating by half power.
· Laser diode is driving with Q101 (650nm LD) and Q102 (780nm LD)
on the DVDM Assy.
Therefore, when short-circuit between the emitter and collector of
these transistors or the base voltage is supplied for transistors turn
on, the laser oscillates. (failure mode)
· In the test mode
, there is the mode that the laser oscillates except
for the disc judgment and playback. LD ON mode in the test mode
oscillates with the laser forcibly.
The interlock mechanism mentioned above becomes invalid in this
mode.
2. When the cover is open, close viewing through the objective lens with
the naked eye will cause exposure to the laser beam.
Additional Laser Caution
for MD
Control method of the current through a laser diode.
The resistor R166 on the MD MOUNT ASSY (For MD mechanism
assembly) are for the limiting of current through a laser diode.
Control method of the laser output power
The laser pick-up assembly provide the photo-diodes and APC (Auto
Power Control) circuit.
The photo-diode detect output of the laser diode then IC201 control the
APC circuit according to the signal voltage of the photo-diode via IC101.
Laser Interlock Switch
The loading position detect switch is set to " LOAD ON " position, IC201
get the " LOAD " signal, and hand the laser " LDON " signal to APC (Auto
Power Control) circuit of the Laser pick-up assembly.
Then a laser diode can be lighted when the " LOAD " signal is " LOAD
ON " position.
VRW1872
LABEL CHECK
background image
XV-SV5DV
3
5
678
56
7
8
C
D
F
A
B
E
[ Important symbols for good services ]
In this manual, the symbols shown-below indicate that adjustments, settings or cleaning should be made securely.
When you find the procedures bearing any of the symbols, be sure to fulfill them:
2. Adjustments
To keep the original performances of the product, optimum adjustments or specification confirmation is indispensable.
In accordance with the procedures or instructions described in this manual, adjustments should be performed.
3. Cleaning
For optical pickups, tape-deck heads, lenses and mirrors used in projection monitors, and other parts requiring cleaning,
proper cleaning should be performed to restore their performances.
5. Lubricants, glues, and replacement parts
Appropriately applying grease or glue can maintain the product performances. But improper lubrication or applying
glue may lead to failures or troubles in the product. By following the instructions in this manual, be sure to apply the
prescribed grease or glue to proper portions by the appropriate amount.For replacement parts or tools, the prescribed
ones should be used.
4. Shipping mode and shipping screws
To protect the product from damages or failures that may be caused during transit, the shipping mode should be set or
the shipping screws should be installed before shipping out in accordance with this manual, if necessary.
1. Product safety
You should conform to the regulations governing the product (safety, radio and noise, and other regulations), and
should keep the safety during servicing by following the safety instructions described in this manual.
DVD-Video
MiniDisc
MiniDisc Long Play
Video CD
Super Video CD (Super VCD)
Audio CD
CD-R
CD-RW
Discs compatible with this player
Any disc that displays one of the following
logos should play in this player. Other
formats, including DVD-Audio, DVD-RAM,
DVD-ROM, CD-ROM (except those that
contain MP3 files), SACD and Photo CD will
not play.
background image
XV-SV5DV
4
1234
123
4
C
D
F
A
B
E
CONTENTS
SAFETY INFORMATION ..................................................................................................................................... 2
1. SPECIFICATIONS ............................................................................................................................................ 5
2. EXPLODED VIEWS AND PARTS LIST ............................................................................................................ 6
2.1 PACKING SECTION .................................................................................................................................. 6
2.2 EXTERIOR SECTION................................................................................................................................ 8
2.3 CHASSIS SECTION ................................................................................................................................ 10
2.4 FRONT PANEL SECTION ....................................................................................................................... 12
2.5 LOADING MECHA ASSY ........................................................................................................................ 14
2.6 APPLICATION OF LUBRICANT FOR LOADING MECHA ASSY ............................................................ 15
2.7 TRAVERSE MECHANISM ASSY-S ......................................................................................................... 16
2.8 MD MECHA (1/2 : LOADING ASSY) ....................................................................................................... 18
2.9 MD MECHA (2/2 : MECHA DECK ASSY)................................................................................................ 20
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM ..........................................................................................22
3.1 OVERALL BLOCK DIAGRAM.................................................................................................................. 22
3.2 DVD SECTION BLOCK DIAGRAM .......................................................................................................... 24
3.3 LOAB ASSY and OVERALL WIRING DIAGRAM..................................................................................... 26
3.4 DVDM ASSY (1/2).................................................................................................................................... 28
3.5 DVDM ASSY (2/2).................................................................................................................................... 30
3.6 DVD IF ASSY ........................................................................................................................................... 32
3.7 FM/AM TUNER MODULE ........................................................................................................................ 34
3.8 MD HELP ASSY ...................................................................................................................................... 36
3.9 CONTROL (1/2) and TX SUPPORT ASSYS ........................................................................................... 38
3.10 CONTROL ASSY (2/2)........................................................................................................................... 40
3.11 LCD, LEDL2, JOG, SW and HP ASSYS ................................................................................................ 42
3.12 REGULATOR and AMP ASSYS ............................................................................................................ 44
3.13 SECONDARY and PRIMARY ASSYS ................................................................................................... 46
3.14 MD MECHA............................................................................................................................................ 48
3.15 WAVEFORMS ........................................................................................................................................ 50
4. PCB CONNECTION DIAGRAM ..................................................................................................................... 51
4.1 LOAB ASSY ............................................................................................................................................. 51
4.2 DVDM ASSY ............................................................................................................................................ 52
4.3 DVD IF ASSY ........................................................................................................................................... 54
4.4 FM/AM TUNER MODULE ........................................................................................................................ 56
4.5 TX SUPPORT ASSY................................................................................................................................ 57
4.6 MD HELP ASSY ...................................................................................................................................... 58
4.7 CONTROL ASSY ..................................................................................................................................... 60
4.8 LCD and LEDL2 ASSYS .......................................................................................................................... 64
4.9 JOG, SW and HP ASSYS ........................................................................................................................ 66
4.10 REGULATOR and AMP ASSYS ............................................................................................................ 68
4.11 SECONDARY ASSY .............................................................................................................................. 70
4.12 MD MECHA............................................................................................................................................ 72
4.13 PRIMARY ASSY .................................................................................................................................... 74
5. PCB PARTS LIST ........................................................................................................................................... 75
6. ADJUSTMENT ............................................................................................................................................... 81
6.1 DVD SECTION......................................................................................................................................... 81
6.1.1 ADJUSTMENT ITEMS AND LACATION ............................................................................................... 81
6.1.2 JIGS AND MEASURING INSTRUMENTS ............................................................................................81
6.1.3 NECESSARY ADJUSTMENT POINTS ................................................................................................ 82
6.1.4 TEST MODE ......................................................................................................................................... 83
6.1.5 MECHANISM ADJUSTMENT ............................................................................................................... 84
6.2 TUNER SECTION .................................................................................................................................... 87
6.3 MD SECTION........................................................................................................................................... 88
7. GENERAL INFORMATION ............................................................................................................................. 97
7.1 DIAGNOSIS ............................................................................................................................................. 97
7.1.1 DVD TEST MODE ................................................................................................................................. 97
7.1.2 DISPLAY OF THE MECHANISM ERROR HISTORY.......................................................................... 103
7.1.3 TEST POINT LOCATION & WAVEFORMS......................................................................................... 106
7.1.4 DVD TROUBLE SHOOTING ............................................................................................................... 110
7.1.5 ERROR CODE TABLE ........................................................................................................................ 112
7.1.6 DISASSEMBLY ................................................................................................................................... 113
7.2 PARTS.................................................................................................................................................... 127
7.2.1 IC ........................................................................................................................................................ 127
7.2.2 DISPLAY ............................................................................................................................................. 148
7.3 CIRCUIT DESCRIPTION ....................................................................................................................... 149
7.4 CLEANING............................................................................................................................................. 150
8. PANEL FACILITIES ...................................................................................................................................... 151
background image
XV-SV5DV
5
5
678
56
7
8
C
D
F
A
B
E
1. SPECIFICATIONS
Amplifier Section
Continuous Power (RMS) ............................................. 25 W + 25 W
(1 kHz, THD 10%, 4
)
Disc section
Digital audio
characteristics ................................................ DVD fs: 96kHz, 24-bit
Type ......................................... DVD system, Video CD system and
Compact Disc digital audio system
Frequency response ................................................. 4 Hz to 44 kHz
(DVD fs: 96 kHz)
MiniDisc section
Recording method ...................................................... Magnetic-field
modulation overwrite type
Playback method ............................................... Non-contact optical
Sampling frequency ............................................................ 44.1kHz
FM tuner section
Frequency Range ..................................................... 87.5 ­ 108MHz
Antenna ................................................................ 75
, unbalanced
AM tuner section
FrequencyRange
With 9 kHz step ........................................... 531kHz to 1,602kHz
With 10 kHz step ......................................... 530kHz to 1,700kHz
Antenna ...................................................................... Loop antenna
Miscellaneous
Power Requirements ................................................ AC 220V, 50Hz
Power Consumption ............................................................... 215 W
Power Consumption in standby mode ................................... 0.36 W
Dimensions:
DVD Tuner Deck ......................... 162 (W) x 220 (H) x 339.5 (D) mm
Weight .................................................................................... 6.3 kg
Accessories
Accessories
Operating instructions .................................................................... 1
Remote control .............................................................................. 1
Dry cell batteries (AA/R6) .............................................................. 2
Power cord ..................................................................................... 1
Video cord ...................................................................................... 1
FM antenna ................................................................................... 1
AM loop antenna ............................................................................ 1
Speaker System S-SV5-S
Enclosure ............................................... Bass-reflex bookshelf type
(magnetically shielded)
System ....................................................................... 2-way system
Speakers:
Woofer ............................................................... 10 cm cone type
Tweeter .......................................................... 20 mm dome type
Nominal impedance ................................................................... 4
Frequency range ..................................................... 55 Hz to 20 kHz
Maximum power ....................................................................... 25 W
Dimensions ................................... 130 (W) x 220 (H) x 242 (D) mm
Weight .................................................................................... 2.0 kg
· Specifications and design subject to possible modification
without notice, due to improvements.
· Remote control
· AA/R6P dry cell batteries x2
· FM wire antenna
· AM loop antenna
· Video cord
· Power cable
* Manufactured under license from Dolby Laboratories. "Dolby"
and the double-D symbol are trademarks of Dolby Laboratories.
* "DTS" is a registered trademark of Digital Theater Systems,
Inc.
* TruSurround and the
® symbol are trademarks of SRS
Labs, Inc. TruSurround technology is incorporated under
license from SRS Labs, Inc.
(064-10001-005)
(043-26182-501)
YELLOW
(015-80004-001)
(AXD7343)
(023-60060-114)
MD
LINE
FM
/AM
DVD
/CD
DVD
AUDIO SUBTITLE ANGLE
ZOOM
SYSTEM
MENU
REPEAT RANDOM
PGM
SURR
SOUND
TOP
MENU
DVD
MENU
DVD SETUP
RETURN
MUTE
VOLUME
5
4
6
8
79
0
2
13
GHI
JKL
MNO
ENTER
PQRS
TUV
WXYZ
MARK
ABC
DEF
CLEAR
TIMER
(CLOCK ADJ)
SYSTEM
DISP/CHARA
DVD
DISP
RECTHIS
FOLDER/GROUP
MD
ST
ST
TUNE
TUNE
STANDBY
/ON

Reviews

There are no reviews of this manual yet.

Related Products

Cover page of PIONEER GRJ320 Owner's Manual

This manual has 82 pages, file size: 4.66 MB. It's available in languages: French, English.

Cover page of PIONEER DEH-2770MP/XM/CS Owner's Manual

This manual has 75 pages, file size: 0.94 MB. It's available in languages: Portuguese, English, Spanish.

Cover page of PIONEER A-9 Service Manual

This manual has 26 pages, file size: 3.99 MB. It's available in languages: English.

Cover page of PIONEER TS-W307F/XCN/ES Owner's Manual

This manual has 2 pages, file size: 10.21 MB. It's available in languages: Portuguese, French, Arabic, English, Russian, Spanish, German, Chinese Simplified, Italian.

Cover page of PIONEER PDF706 Service Manual

This manual has 35 pages, file size: 2.27 MB. It's available in languages: English.
