SENNHEISER PMX 680 SPORTS Owner's Manual

Cover page of SENNHEISER PMX 680 SPORTS Owner's Manual

Owner's Manual for SENNHEISER PMX 680 SPORTS, downloadable as a PDF file.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 6 pages
  • File size: 0.42 MB
  • Available language versions: English
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6Thumbnail of page 7Thumbnail of page 8
Thumbnail of page 9
background image
rinted in China
bl. 10/09, A01
Instruction manual
PMX 680 SPORTS
background image
rinted in China
bl. 10/09, A01
Instruction manual
PMX 680 SPORTS
background image
1
Important safety
instructions
In order to prevent damage to health:
Set the volume to a low level before
putting the earphones on.
Avoid listening at high volume levels for
long periods of time.
The
earphones
contain
magnets
that
generate a magnetic field which could cause
interference with cardiac pacemakers and
implanted defibrillators.
Keep the earphones at least 1.2" (3 cm)
from cardiac pacemakers or implanted
defibrillators.
In order to prevent accidents:
Do not wear the earphones in an environ-
ment that requires your special attention
(e.g. in traffic).
Keep the earphones and accessory parts
out of reach of children who could
swallow smaller pieces.
In
order
to
prevent
damage
to
the
earphones:
Do not heat the earphones (hairdryer,
heating, extended exposure to sunlight,
etc.).
Do not store wet earphones in a bag.
Delivery includes
1 pair of PMX 680 Sports neckband
earphones
1 pair of ear pads
1 extension cable with volume control
1cable clip
1storage pouch
1 instruction manual
Adjusting the earphones
Attach the ear pads to the earphones.
Accessory parts are available from
your Sennheiser partner. To find your
Sennheiser partner, please visit our
website
at
www.sennheiser.com
> Service & Support > Service Partners.
background image
2
Putting on the earphones
To ensure the best possible sound perfor-
mance, use the supplied ear pads. Place the
earphones at an angle and as close as
possible in front of your ear canals:
Put on the earphones as shown.
Optimum cable routing
Ensure that the cable is routed close to
the body, but that your freedom of
movement is not restricted.
To relieve cable strain and reduce body
sound:
Use the supplied cable clip.
WARNING Hearing damage due to high
volumes!
Listening at high volume levels
for long periods can lead to
permanent hearing defects.
Avoid listening at high volume
levels for long periods of time.
L
R
LR
background image
3
Adjusting the volume
Use the supplied extension cable with
volume control if you want to wear your
audio source e.g. attached to your waist-
band.
Cleaning the earphones
Remove the ear pads and the ear sleeves
from the earphones.
Use a cloth to carefully remove buildup
from the earphones and ear pads.
Or:
Carefully rinse the earphones under luke-
warm running water.
Then allow the earphones to air dry at
room temperature.
CAUTION
Danger of damage to the earphones!
Contact with any liquid under pressure or
extended contact with any liquid can cause
it to seep into the earphone housing
resulting in damage to the earphone.
Do not use any solvents or cleansing
agents.
Do not immerse the earphones into water
for extended periods of time.
Do not expose the earphones to excessive
water pressure.
background image
4
Specifications
Manufacturer Declarations
Warranty
Sennheiser electronic GmbH & Co. KG gives a
warranty of 24 months on this product.
For the current warranty conditions, please
visit our website at www.sennheiser.com
under "Service & Support" or contact your
Sennheiser partner.
Declaration of Conformity
WEEE Declaration
The
declarations
are
available
at
www.sennheiser.com.
Frequency response 18 to 20,000 Hz
SPL
120 dB
(1 kHz/1 Vrms)
Impedance
16
Weight
Approx. 18 g
This product is in compliance with
the
essential
requirements
and
other relevant provisions of direc-
tives:
EMC 2004/108/EC
RoHS 2002/95/EC
WEEE 2002/96/EC
Please dispose of this product by
taking it to your local collection
point or recycling center for such
equipment.
