9A09897700

DVD Player

OWNER'S MANUAL

DV-3300VK

9A09897700

DVD Player

OWNER'S MANUAL

DV-3300VK

Contents

Thank you for choosing TEAC. Read this manual carefully to get

the best performance from this unit.

Remote Control Unit .............................................................................. 2

Before Use .............................................................................................. 3

Discs ........................................................................................................ 4

Connection ............................................................................................. 6

Names of Each Control ......................................................................... 8

Playback ............................................................................................... 10

Playback from a Specific Chapter/Track ........................................ 12

Slow-Motion Playback ....................................................................... 13

Direct Playback (except DVD) ........................................................... 13

Title or Chapter Select (DVD) ............................................................ 14

Time Select (DVD) ............................................................................... 15

Display ................................................................................................... 16

Dimmer .................................................................................................. 16

Sleep Timer .......................................................................................... 16

Picture Zoom......................................................................................... 17

Select a Subtitle Language................................................................. 17

Select an Audio ................................................................................... 18

Audio Channel Selection .................................................................... 18

Change the Angle ................................................................................ 18

Repeat Playback................................................................................... 19

Programmed Playback ....................................................................... 20

Karaoke functions ............................................................................... 21

Settings ................................................................................................. 22

TV DISPLAY ................................................................................... 23

TV SYSTEM .................................................................................... 23

VIDEO OUTPUT ............................................................................. 23

OSD LANG ...................................................................................... 23

DOWNMIX ..................................................................................... 24

DIGITAL OUTPUT .......................................................................... 24

DYNAMIC ....................................................................................... 24

AUDIO ............................................................................................. 25

DISC MENU ................................................................................... 25

PARENTAL ..................................................................................... 25

PASSWORD ................................................................................... 25

DEFAULTS ...................................................................................... 25

Troubleshooting ................................................................................... 26

Specifications ...................................................................................... 27

Remote Control Unit

Remove the battery compartment cover.

Insert two "AA" (R6, SUM-3) dry batteries. Make sure that the

batteries are inserted with their positive "+" and negative "_"

poles positioned correctly.

Close the cover.

Battery Replacement

If the distance required between the remote control unit and main

unit decreases, the batteries are exhausted. In this case replace

the batteries with new ones.

Precautions concerning batteries

< Be sure to insert the batteries with correct positive "+" and

negative "_" polarities.

< Use batteries of the same type. Never use different types of

batteries together.

< Rechargeable and non-rechargeable batteries can be used.

Refer to the precautions on their labels.

< When the remote control unit is not to be used for a long time

(more than a month), remove the batteries from the remote

control unit to prevent them from leaking. If they leak, wipe

away the liquid inside the battery compartment and replace the

batteries with new ones.

< Do not heat or disassemble batteries and never dispose of old

batteries by throwing them in a fire.

The provided Remote Control Unit allows the unit to be operated

from a distance.

When operating the remote control unit, point it towards the

REMOTE SENSOR on the front panel of the unit.

< Even if the remote control unit is operated within the effective

range, remote control operation may be impossible if there are

any obstacles between the unit and the remote control.

< If the remote control unit is operated near other products

which generate infrared rays, or if other remote control

devices using infrared rays are used near the unit, it may

operate incorrectly. Conversely, the other products may

operate incorrectly.

Battery Installation

CAUTION

The product shall not be exposed to dripping or splashing and

that no object filled with liquids, such as vases, shall be placed

on the product.

Do not install this equipment in a confined space such as a

book case or similar unit.

Before Use

Conventions about This Manual

< This Owner's Manual largely describes how to control the

DV-3300VK using the included RC-926 remote control unit. The

duplicate buttons on the DV-3300VK provide the same

functions.

< The types of functions and operations that can be used for a

particular disc vary depending on the features of that disc. In

some cases, these functions and operations may differ from

the descriptions given in this Owner's Manual. In this event,

follow the instructions given on the screen. This Owner's

Manual only covers basic disc operations.

< For some operations, the PROHIBIT icon "" may appear on

the screen. This indicates that the operation described in this

Owner's Manual is not permitted for the current disc.

< The drawings about the TV screen and front panel display

used in this Owner's Manual are purely for the purposes of

explanation. The actual displays may differ slightly from what

are shown here.

Read this before operation

< As the unit may become warm during operation, always leave

sufficient space above the unit for ventilation.

< The voltage supplied to the unit should match the voltage as

printed on the rear panel. If you are in any doubt regarding this

matter, consult an electrician.

< Choose the installation location of your unit carefully. Avoid

placing it in direct sunlight or close to a source of heat. Also

avoid locations subject to vibrations and excessive dust, heat,

cold or moisture.

< Do not place the unit on the amplifier/receiver.

< Do not open the cabinet as this might result in damage to the

circuitry or electrical shock. If a foreign object should get into

the set, contact your dealer.

< When removing the power plug from the wall outlet, always

pull directly on the plug, never yank the cord.

< To keep the laser pickup clean, do not touch it, and do not

forget to close the disc tray.

< Do not attempt to clean the unit with chemical solvents as this

might damage the finish. Use a clean, dry cloth.

< Keep this manual in a safe place for future reference.

DO NOT MOVE THE UNIT DURING PLAYBACK

During playback, the disc rotates at high speed. Do NOT lift or

move the unit during playback. Doing so may damage the disc.

WHEN MOVING THIS UNIT

When changing places of installation or packing the unit for

moving, be sure to remove the disc and return the disc table to

its original position in the player. Then, press the power switch

to turn the power off, and disconnect the power cord. Moving

this unit with the disc loaded may result in damage to this unit.

"DTS" and "DTS Digital Out" are trademarks of Digital Theater

reserved.

Manufactured under license from Dolby Laboratories. "Dolby",

"Pro Logic" and the double-D symbol are trademarks of Dolby

Laboratories.

This product incorporates copyright protection technology that

is protected by method claims of certain U.S. patents and other

intellectual property rights owned by Macrovision Corporation

and other rights owners. Use of this copyright protection

technology must be authorized by Macrovision Corporation,

and is intended for home and other limited viewing uses only,

unless otherwise authorized by Macrovision Corporation.

Reverse engineering or disassembly is prohibited.

Discs

Region Number of DVD Video discs:

DVD players and discs are designed with region numbers that

dictate the regions in which a disc can be played. If the region

number on the disc you want to play does not match the region

number of your DVD player, you will not be able to play the disc.

In that case, an error message will appear on the screen.

The region number is printed on the rear panel of this unit.

About CD-R/CD-RW

CD-R/RW discs recorded in Audio CD format and finalized

correctly are playable. But depending on the quality of the disc

and/or the condition of the recording, some CD-R & CD-RW discs

may not be playable.

DVD Video:

· Single-sided or double-sided discs

· Single layer or dual layer discs

· Dolby Digital, DTS, MPEG or Linear PCM digital

audio

· MPEG-2 digital video

· This unit can play DVD-R/DVD-RW discs

recorded in DVD video format.

Discs are generally divided into one or more titles.

Titles may be further subdivided into chapters.

Audio CD:

· 12cm or 8cm discs

· Linear PCM digital audio

Audio CDs are divided into tracks.

Video CD:

· 12cm or 8cm discs

· MPEG-1 digital audio

· MPEG-1 digital video

Video CDs are divided into tracks.

SVCD:

· 12cm or 8cm discs

· MPEG-1 Audio Layer2

· MPEG-2 digital video

Type of Discs That Can be Played on This

System

This player can playback discs bearing any of the following logos:

MP3/JPEG compatibility

This player is compatible with CD-R, CD-RW and CD-ROM (Kodak

picture CD, etc.) discs that contain MP3 audio tracks or JPEG

files.

< File names of MP3/JPEG should be alphanumeric characters.

This unit cannot display symbols and full-size or 2 bytes-wide

characters (such as Japanese, Chinese, etc.) correctly. Also,

be sure to use the file extension "mp3", "jpg" or "jpeg".

< Only the first 8 characters of folder and track names

(excluding the "mp3", "jpg" or "jpeg" extension) are displayed.

< Use CD-R or CD-RW media for recording your MP3 or JPEG

files. The disc must be finalized in order to play.

< The CD-ROM must be ISO 9660 compatible.

< This player is not compatible with multi-session discs.

< When more than 200 files or folders are recorded on the disc,

the unit might not be able to play it correctly.

< It may take time to display a progressive JPEG picture.

< Depending on the file size and compression rate, some JPEG

pictures cannot be displayed correctly.

< Mono or stereo MPEG-1 Audio Layer 3 format, 44.1 or 48kHz,

fixed bit-rate.

< Not compatible with variable bit-rate (VBR) files.

< Audio encoded at 128Kbps should sound close to regular audio

CD quality. Although this player will play lower bit-rate MP3

tracks, the sound quality becomes noticeably worse at lower

bit-rates.

Caution:

< If you record a disc using a personal computer or a DVD

recorder, even if it is recorded in a compatible format, there

are cases in which it may not play because of the settings of

the application software used to create the disc. (Check with

the software publisher for more detailed information.)

< Unfinalized DVD-R/RW discs cannot be played.

Following discs cannot be played with this

unit:

· CD-G, Data part of CD-EXTRA, PHOTO CD, CD-ROM, SACD, DVD-

Audio, DVD-RAM and DVD-ROM discs

· discs recorded in a color system other than PAL or NTSC

· illegally produced discs

· scratched discs

· discs that are dusty, soiled or marked with fingerprints

Warning:

If you attempt to play back such discs, there is a risk that sudden

loud noise can blast over the speakers at full volume and cause

damage to the speakers and your hearing.

Copy-protected discs and other discs which do not conform to

the CD standard may not play back correctly in this player. If you

use such discs in this unit, TEAC Corporation and its subsidiaries

cannot be responsible for any consequences or guarantee the

quality of reproduction. If you experience problems with such

non-standard discs, you should contact the producers of the disc.

number of audio tracks recorded

on the disc

number of subtitles recorded on

the disc

screen aspect ratio

disc recorded with multiple

camera angles

region code

Example of Icons used on DVD discs:

How to remove the disc

How to hold the disc

< Always place the disc on the disc tray with the label side

uppermost. (Compact discs can be played or recorded only on

one side.)

< To remove a disc from its storage case, press down on the

center of the case and lift the disc out, holding it carefully by

the edges.

< Should the disc become dirty, wipe the surface radially (from

the center hole outward towards the outer edge) with a soft,

dry cloth:

< Never use such chemicals as record sprays, antistatic sprays

or fluid, benzine or thinner to clean the discs. Such chemicals

will do irreparable damage to the disc's plastic surface.

< Discs should be returned to their cases after use to avoid dust

and scratches that could cause the laser pickup to "skip."

< Do not expose discs to direct sunlight or high humidity and

temperature for extended periods. Long exposure to high

temperatures will warp the disc.

< Do not play any disc that is warped, deformed or damaged.

Playing such discs may cause irreparable harm to the playing

mechanisms.

< CD-R and CD-RW discs are more sensitive to the effects of

heat and ultraviolet rays than ordinary CDs. It is important that

they are not stored in a location where direct sunlight will fall

on them, and which is away from sources of heat such as

radiators or heat-generating electrical devices.

< Printable CD-R and CD-RW discs aren't recommended, as the

label side might be sticky and damage the unit.

< Do not stick papers or protective sheets on the discs and do

not use any protective coating spray.

< Use a soft oil-based felt-tipped pen to write the information on

the label side. Never use a ball-point or hard-tipped pen, as

this may cause damage to the recorded side.

< Never use a stabilizer. Using commercially available CD

stabilizers with this unit will damage the mechanisms and

cause them to malfunction.

< Do not use irregular shape CDs (octagonal, heart shaped,

business card size, etc.). CDs of this sort can damage the unit:

< If you are in any doubt as to the care and handling of a

CD-R/CD-RW disc, read the precautions supplied with the disc,

or contact the disc manufacturer directly.

Track 1

Track 2

Track 3

Track 4

Chapter 1

Chapter 2

Chapter 1

Chapter 2

Title 1

Glossary of Disc Terms

Title (DVD)

The longest sections of a picture or a music piece on a DVD; a

movie, et cetera, for a picture piece on a video software; or an

album, etc., for a music piece on an audio disc. Each title is

assigned a title number enabling you to locate the title you

want. On most DVD movies, there will be only one title.

Chapter (DVD)

Sections of a picture or a music piece that are smaller than

titles. A title is composed of several chapters. Each chapter is

assigned a chapter number enabling you to locate the chapter

you want. Depending on the disc, there may be only one

chapter per title recorded.

Track (Video or Audio CD)

Sections of a picture or a music piece on a VIDEO or an audio

CD. Each track is assigned a track number enabling you to

locate the track you want. On most audio CD's, one track is

equal to one song.

Title 2

DVD

VCD

Track 1

Track 2

Track 3

Track 4

Reviews

There are no reviews of this manual yet.

Related Products

Cover page of TEAC RW-H300 Service Manual

TEAC DV3300VK Owner's Manual

Manual details

We guarantee that...

Sample pages

Reviews

Related Products

TEAC RW-H300 Service Manual

TEAC W600R Owner's Manual

TEAC EXM3 Owner's Manual

TEAC AGH350 Service Manual

TEAC W600R Service Manual

Popular Brands

General

Members Area
