2 SPECIFICATIONS
3
DVD Player
Pickup: Semiconductor laser, Wavelength 650 nm
Signal system: NTSC / PAL
Video signal horizontal resolution: More than 480 lines (DVD)
Video signal-to-noise ratio: More than 60 dB (DVD)
Audio frequency response (at 2 CH stereo mode):
DVD (PCM): 2 Hz ~ 22 kHz (+/- 1.0 dB)
CD: 2 Hz ~ 20 kHz (+/- 1.0 dB)
Audio signal-to-noise ratio: More than 80 dB
Total harmonic distortion: Less than 0.01%
Dynamic range:
DVD (PCM): More than 85 dB (2kHz, -60 dBFS)
CD: More than 85 dB
FM Tuner
System: PLL quartz-locked digital synthesizer system
Tuning range:
87.50 ~ 108.00 MHz (50 kHz step-European Model)
87.50 ~ 108.00 MHz (100 kHz step-General Export Model)
Antenna: FM pigtail antenna
Antenna terminals: 75 ohms, unbalanced
Intermediate frequency: 10.7 MHz
AM Tuner
System: PLL quartz-locked digital synthesizer system
Tuning range:
522 ~ 1620 kHz (9 kHz interval) (European Model)
530 ~ 1710 kHz (10 kHz interval) (General Export Model)
Antenna: AM Loop antenna
Video outputs
CVBS Video: 1 Vp-p 75 ohms
S-video: Y: 1 Vp-p 75 ohms
C: PAL 0.3 Vp-p 75 ohms / NTSC 0.286 Vp-p 75 ohms
Audio line outputs
Audio L/R: 2 Vrms, 1 kilohms
Subwoofer: 5 Vrms maximum (adjustable), 1 kilohms
Audio power outputs
Stereo mode: 20 W + 20 W (4 ohms at 1 kHz, THD 10%)
Surround mode:
Front: 20 W + 20 W (4 ohms at 1 kHz, THD 10%)
Center: 20 W (4 ohms at 1 kHz, THD 10%)
Rear: 20 W + 20 W (4 ohms at 1 kHz, THD 10%)
· Phones: Accepts low- and high-impedance headphones
Speakers
Active Subwoofer:
Power: 50 W (4ohms at 80 Hz, THD 10%)
Speaker system: Bass reflex
Speaker unit: 8 inches, dia. cone type
Rated impedance: 4 ohms
Dimensions: W160 x H333 x D222 mm
Weight: 5.0 kg
Front / Center / Rear speakers:
Power: 20 W maximum
Speaker system: Bass reflex
Speaker unit: 2 7/8 inches, dia. cone type
Rated impedance: 4 ohms
Dimensions: W99 x H105 x D100 mm
Weight: 0.8 kg
General
Power requirements:
120V AC, 60 Hz (General Export Model)
230 V AC, 50 Hz (European Model)
240 V AC, 50 Hz (Australian Model)
Power consumption: 250 W
Dimensions: W417 x H68 x D355 mm
Weight: 8.5 kg
Operating temperature: 5 °C ~ 40 °C
Operating humidity: 5% ~ 90%
Storage temperature: -20 °C ~ 55 °C
Supplied accessories:
AM loop antenna x 1
FM antenna x 1
Speaker cable (5m x 3, 10 m x 2)
RCA cable (for Subwoofer) x 1
Stickers to protect speakers x 1
Remote control unit x 1
Batteries (AA, R6, SUM-3) x 2
· Design and specifications are subject to change without notice.
· Weight and dimensions are approximate.
