background image
9A10076000
SL-D88
CD Receiver
OWNER'S MANUAL
MANUEL DU PROPRIÉTAIRE
Z
?
FRANÇAIS
ENGLISH
background image
9A10076000
SL-D88
CD Receiver
OWNER'S MANUAL
MANUEL DU PROPRIÉTAIRE
Z
?
FRANÇAIS
ENGLISH
background image
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in
accordance with the manufacturer's instructions.
8) Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety.
If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete
outlet.
10) Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11) Only use attachments/accessories specified by the
manufacturer.
12) Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or
when unused for long periods of time.
14) Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate
normally, or has been dropped.
<
Do not expose this apparatus to drips or splashes.
<
Do not place any objects filled with liquids, such as
vases, on the apparatus.
<
Do not install this apparatus in a confined space such
as a book case or similar unit.
<
The apparatus draws nominal non-operating power
from the AC outlet with its POWER switch in the off
position.
2
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
"dangerous voltage" within the product's
enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
IMPORTANT SAFETY
INSTRUCTIONS
background image
ENGLISH
3
For U.S.A.
Optical pickup :
Type
: CMS-B31
Manufacturer : SAMSUNG
Laser output
: 0.5mW on the objective lens
Wavelength
: 760 - 800 nm
(rear panel of the unit)
CAUTION
<
DO NOT REMOVE THE EXTERNAL CASES OR
CABINETS TO EXPOSE THE ELECTRONICS. NO USER
SERVICEABLE PARTS ARE WITHIN!
<
IF YOU ARE EXPERIENCING PROBLEMS WITH THIS
PRODUCT, CONTACT TEAC FOR A SERVICE
REFERRAL. DO NOT USE THE PRODUCT UNTIL IT
HAS BEEN REPAIRED.
<
USE OF CONTROLS OR ADJUSTMENTS OR
PERFORMANCE OF PROCEDURES OTHER THAN
THOSE SPECIFIED HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.
WARNING : TO PREVENT FIRE OR
SHOCK HAZARD, DO NOT EXPOSE
THIS
APPLIANCE
TO
RAIN
OR
MOISTURE.
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses, and
can radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
off and on, the user is encouraged to try to correct
the interference by one or more of the following
measures:
· Reorient or relocate the equipment and/or the
receiving antenna.
· Increase the separation between the equipment
and receiver.
· Connect the equipment into an outlet on a
circuit different from that to which the receiver is
connected.
· Consult the dealer or an experienced radio/TV
technician for help.
CAUTION
Changes or modifications to this equipments not
expressly approved by TEAC CORPORATION for
compliance will void the user's warranty.
For U.S.A.
This product has been designed and manufactured
according to FDA regulations "title 21, CFR, chapter 1,
subchapter J, based on the Radiation Control for
Health and Safety Act of 1968", and is classified as
class 1 laser product. There is not hazardous invisible
laser radiation during operation because invisible laser
radiation emitted inside of this product is completely
confined in the protective housings.
The label required in this regulation is shown
.
background image
4
Contents
Thank you for choosing TEAC. Read this manual
carefully to get the best performance from this
unit.
IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . . . . . 2
Before Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Compact Disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Names of Each Control . . . . . . . . . . . . . . . . . . . . . . . 6
Playing a CD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Programmed Playback. . . . . . . . . . . . . . . . . . . . . . . 10
Repeat Playback/Shuffle Playback . . . . . . . . . . . . . . 12
Listening to the Radio . . . . . . . . . . . . . . . . . . . . . . 13
Listening the the Extenal Sources . . . . . . . . . . . . . . 13
Clock Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Sleep Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Before Use
Read this before operation
<
As the unit may become warm during operation,
always leave sufficient space around the unit for
ventilation.
<
The voltage supplied to the unit should match the
voltage as printed on the rear panel. If you are in
any doubt regarding this matter, consult an
electrician.
<
Choose the installation location of your unit
carefully. Avoid placing it in direct sunlight or close
to a source of heat. Also avoid locations subject to
vibrations and excessive dust, heat, cold or
moisture.
<
Do not place the unit on any high heat-producing
units like your amplifier/receiver.
<
Do not use the unit in the hot place (over
85°F/30°C).
<
Do not open the cabinet as this might result in
damage to the circuitry or electrical shock. If a
foreign object should get into the set, contact your
dealer or service agency.
<
When removing the power plug from the wall
outlet, always pull directly on the plug, never yank
the cord.
<
To keep the laser pickup clean, do not touch it, and
do not leave the CD compartment open.
<
Do not attempt to clean the unit with chemical
solvents as this might damage the finish. Use a
clean, dry cloth.
<
Keep this manual in a safe place for future
reference.
DO NOT MOVE THE UNIT DURING CD PLAYBACK
During playback, the disc rotates at high speed. Do
NOT lift or move the unit during playback. Doing so
may damage the disc.
WHEN MOVING THIS UNIT
When changing places of installation or packing the
unit for moving, be sure to remove the disc. Then,
press the power switch to switch the unit back to
standby, and disconnect the power cord. Moving
this unit with the disc loaded may result in damage
to this unit.
Beware of condensation
When the unit (or a disc) is moved from a cold to a
warm place, or used after a sudden temperature
change, there is a danger of condensation; vapor in
the air could condense on the internal mechanism,
making correct operation impossible. To prevent
this, or if this occurs, leave the unit for one or two
hours with the power turned on. The unit will
stabilize at the temperature of its surroundings.
Maintenance
If the surface of the unit gets dirty, wipe with a soft
cloth or use diluted neutral cleaning liquid. Be sure
to remove any fluid completely. Do not use thinner,
benzine or alcohol as they may damage the surface
of the unit.
CAUTION
The product shall not be exposed to dripping or
splashing and that no object filled with liquids, such
as vases, shall be placed on the product.m
Do not install this equipment in a confined space
such as a book case or similar unit.
background image
Discs which can be played on this unit:
· Conventional audio CDs bearing the "Compact
Disc Digital Audio" logo:
?
· Properly finalized CD-R and CD-RW discs
Note:
<
Depending on the quality of the disc and/or the
condition of the recording, some CD-R and CD-RW
discs may not be playable.
<
Copy-protected discs and other discs which do not
conform to the CD standard may not play back
correctly in this player.
If you use such discs in this unit, TEAC Corporation
and its subsidiaries cannot be responsible for any
consequences or guarantee the quality of
reproduction. If you experience problems with such
non-standard discs, you should contact the
producers of the disc.
5
ENGLISH
Compact Disc
<
Never use such chemicals as record sprays,
antistatic sprays or fluid, benzine or thinner to clean
the discs. Such chemicals will do irreparable
damage to the disc's plastic surface.
<
Discs should be returned to their cases after use to
avoid dust and scratches that could cause the laser
pickup to "skip."
<
Do not expose discs to direct sunlight or high
humidity and temperature for extended periods.
Long exposure to high temperatures will warp the
disc.
<
CD-R/CD-RW discs are more sensitive to the effects
of heat and ultraviolet rays than ordinary CDs. It is
important that they are not stored in a location
where direct sunlight will fall on them, and which is
away from sources of heat such as radiators or
heat-generating electrical devices.
<
Printable CD-R/CD-RW discs aren't recommended,
as the label side might be sticky and damage the
unit.
<
Do not stick papers or protective sheets on the
discs and do not use any protective coating spray.
<
Use a soft oil-based felt-tipped pen to write the
information on the label side. Never use a ball-point
or hard-tipped pen, as this may cause damage to
the recorded side.
<
Never use a stabilizer. Using commercially available
CD stabilizers with this unit will damage the
mechanisms and cause them to malfunction.
<
Do not use irregular shape CDs (octagonal, heart-
shape, etc.). CDs of this sort can damage the unit.
<
Always place the disc on the disc tray with the label
side uppermost. (Compact discs can be played or
recorded only on one side.)
<
To remove a disc from its storage case, press down
on the center of the case and lift the disc out,
holding it carefully by the edges.
How to remove the disc
How to hold the disc
<
Should the disc become dirty, wipe the surface
radially with a soft, dry cloth.
<
If you are in any doubt as to the care and handling
of a CD-R/CD-RW disc, read the precautions
supplied with the disc, or contact the disc
manufacturer directly.

Reviews

There are no reviews of this manual yet.

Related Products

Cover page of TEAC CR7 Service Manual

This manual has 114 pages, file size: 36.97 MB. It's available in languages: Japanese, English.

Cover page of TEAC VRDS7 Owner's Manual

This manual has 64 pages, file size: 21.65 MB. It's available in languages: French, English, Spanish, Dutch, German, Italian.

Cover page of TEAC MMC-38 Owner's Manual

This manual has 12 pages, file size: 0.43 MB. It's available in languages: English.

Cover page of TEAC VRDST1 Owner's Manual

This manual has 64 pages, file size: 23.13 MB. It's available in languages: French, English, Spanish, Dutch, German, Italian.

Cover page of TEAC V-580 Service Manual

This manual has 30 pages, file size: 11.57 MB. It's available in languages: English.
